36 Model 6036
Operation
Function Indicator Lights
A. Park Brake Light
(Figure 18)
The park brake light (Figure 18, 1) illuminates any time the park brake is
applied and the ignition switch is in the RUN position.
B. High Beam Light
(used with optional road
light package only)
(Figure 18)
The high beam light (Figure 18, 2) illuminates when the road option
headlights are on full (high) beam and will turn OFF when the
headlights are switched to low beam.
C. Turn Signal Light
(used with optional road
light package only)
(Figure 18)
The turn signal light (Figure 18, 3) will illuminate and flash when the
road option turn signals are activated in either direction or when the
road option hazard lights are activated.
Figure 18
P
OH2480
OH2490
OH2510
0000 00
P
OH1810
1
2
3
