27
Points 4 and 5 depend on the cooker type
4.
Unscrew the large clips on the left and right and
remove them (Fig. C). Remove the middle glass
panel.
5.
Remove the small clips from the lower glass panel
and remove the panel upwards at an angle
(Fig.ĂC).
Clean the glass panels with glass cleaner and a soft
cloth.
or
4.
Unscrew the large clips on the left and right and
remove them (Fig. C). Remove the middle panel.
5.
Remove the small clips from the lower glass panel
and remove the panel upwards at an angle
(Fig.ĂC).
Make sure that the message Right above" is upside
down at the bottom left of both panels.
1.
Slide in the lower glass panel at an angle towards
the rear (Fig. D).
2.
Put the small clips on the left and rightĆhand sides
of the lower panel.
Installation
