9 vmware server – Belkin OmniViewIP 5000HQ User Manual
Page 68
64
OmniView IP 5000 HQ
COnfIGUrInG aCCess serVICes – InTrODUCTIOn
sections
1
3
5
7
9
11
13
15
17
19
2
4
6
8
10
12
14
16
18
20
21
11 .1 .9 VMware server
Click “VMware Server”. The following are the default settings for
VMware Server.
Figure 78 VMware Server
Description – Description of the Access Service: VMware Server
Url/Host – Type the host/IP of the VMware Server resource.
application – vmware.exe is the application used for VMware Server
access. The VMware Server Client application can be obtained from:
http://www.vmware.com/download/server/
application Path – VMware Server console must be installed on
all client computers, preferably in the same path. In the default path
%ProgramFiles%\ VMware\VMware Server Console (see Figure 78), the
application could be in any drive in the Program Files\VMware\VMware
Server Console folder. See the general notes above about variables.
Virtual Machine Path – Type the Virtual Machine Path on the
VMware Server.
login Method:
• Prompt for Credentials – This means the VMware Server Console
login appears and you log in manually.
• Use OmniView IP HQ Credentials – This means OmniView IP
5000HQ logs in to VMware Server Console with the currently logged
user credentials. Ensure that VMware Server is configured to
recognize the same user name and password.
• Use the Following Credentials – Where the user name and password
are different for OmniView IP 5000HQ and VMware Server, select
this option. User name and password fields appear. Type the
VMware Server user name and password. OmniView IP 5000HQ
logs in to VMware Server using this user name and password.
