LK3-B448E MARK II /BA-16
67
17. Adjustment guide refer to this guide when different button are used
When button
diameter (D)
changes
Adjust button selector
Adjust button guide
Vibrating Bowl
Shoot Coil assy
Button Slide Base
Button Catch Plate
Feeder Installation
Position
Machine Head
Adjust button adjustment dial
Adjust button clamp width
When button
thickness (t)
changes
Replace the spacer (S)
Page
Adjust height control plate
When button
hole gap (B)
changes
Adjust needle location
Replace the button carrier
Adjust right/left needle and
button carrier pin positions
Adjust slide base width
Adjust the stopper
Replace the button top cover
Replace the shoot coil
17. Adjustment guide refer to this guide when different button
are used
D
t
B
