LK3-B448E MARK II /BA-16
15
3. Installation
■ Button feeder connection
Pull on the connector to make sure it will not come disconnected after connecting the pins.
■ Control box (for vibrating bowl) connection
Connect the ground wire from the vibrating bowl to the motor.
Button feed
sensor 6P
9P
7P
20P
20P connector
control box
White
White
Red
Black
White
6P connector
Botton stopper solenoid 9P connector
(machine head) Button feeder switch
Black
White
Red
Green
Yellow
Brown
Blue
7P connector
control box
(for vibrating bowl)
Black White Red
Green
Y
ellow
Brown
Blue
Black
9P connector 2P connector
3P connector (male) 9P connector (female)
Green/
Yellow
Black
White
White
Black
Red
