Generatorisshownwithroof,plasticaccesscoverand
controlpanelcoverremovedforclarity.
A - Air Cleaner—Usesadrytypefilterelementandfoam
precleanertoprotectenginebyfilteringdustanddebris
outofintakeair.
B - Engine Label—Identifiesenginemodelandtype.
C - Oil Fill Cap/Dipstick —Checkandaddrecommended
engineoilhere.
D - Control Panel—Usedforvarioustest,operationand
maintenancefunctions.SeeSystem Control Panelonthe
nextpage.
E - Oil Drain Hose—Locatedinsideaccesscoveronside
panel.Providedtofacilitateoilchanging.
F - Unit Identification Label—Identifiesunitbyserial
number.
G - Battery—1VoltDC,sealedbatteryprovidespowerto
starttheengine.
H - Lifting Pocket—Providedateachcornerforlifting
generator.
J - Fuel Inlet—Attachappropriatefuelsupplytogenerator
here.
K - Exhaust Port—High-performancemufflerlowersengine
noisetocomplywithmostresidentialcodes.
L - Oil Filter—Filtersengineoiltoprolonggeneratorlife.
D
A
C
E
B
G
K
H
J
L F
Features and Controls
Home Generator
Read this Operator’s Manual and Safety Rules before operating your generator.
Comparetheillustrationswithyourgeneratortofamiliarizeyourselfwiththelocationsofvariouscontrolsand
adjustments.Save this manual for future reference.
