6. FIXING UNIT
PR99042
REF.NO.
CODE
Q'TY
DESCRIPTION
REMARK
1-11
UL8750001
1 FIXING UNIT, 120V (SP)
1-11
UL8751001
1 FIXING UNIT, 230V (SP)
1-11
UL8833001
1 FIXING UNIT, LEG 230V (SP)
1
UH3306001
1 HALOGEN LAMP Y, 120V (SP)
1
UH3307001
1 HALOGEN LAMP Y, 230V (SP)
2
087411616
2 TAPTITE, CUP B M4X16
3
085311216
2 TAPTITE, BIND B M3X12
4
083311017
2 TAPTITE, PAN B M3X10
5
UL8757001
1 HEAT ROLLER YS (SP)
5
UL8834001
1 HEAT ROLLER, LEG (SP)
6
UH3178000
2 H/R BEARING Y
7
UL8758001
1 H/R CLEANER
7
UL8855001
1 H/R CLEANER, LEG
8
UL8754001
1 H/R WASHER
9
UL6667001
1 THERMISTOR ASSY
CHNG
10
UH3323001
4 EJECT PINCH ROLLER ASSY
11
UL6682001
4 PINCH SPRING
MODEL MFC-P2000/HL-P2000 84U-901/902-050/051/052
T/I NO. PR98271 / PR98292 / PR98303
8. MAIN PCB
REF.NO.
CODE
Q'TY
DESCRIPTION
SYMBOL
REMARK
1-1
UK4250001
1 MAIN PCB ASSY, US (SP)
B512018-100C
1-1
UK4251001
1 MAIN PCB ASSY, EUR (SP)
B512018-101B
1-1
UK4252001
1 MAIN PCB ASSY, HEB (SP)
B512018-102
1
UK4328000
1 MROMP2000, US
#4
1
UK4320000
1 MROMP2000, EUR
#4
1
UK4160000
1 MROMP2000, HEB
#4
MODEL MFC-P2000/HL-P2000 84U-901/902-101/102/103
T/I NO. PR98260
