TECRA A3/S2 4-11
Operating Basics
5. Slide the Slim Select Bay latch to the unlock position.
6. Grasp the DVD-ROM drive and slide it out.
Removing the DVD-ROM drive
Inserting a module
Insert the Slim Select Bay Hard disk drive adaptor as described below.
1. Insert the Slim Select Bay Hard disk drive adaptor in the computer as
shown below and press until the ejector clicks.
2. If you want to lock the Slim Select Bay Hard disk drive adaptor, set the
Slim Select bay lock screw in the hole for the lock position
➁
. The lock
screw is inserted in the unlock position
➀
at the time of purchasing.
Inserting the Slim Select Bay HDD adaptor
The DVD-ROM drive and other Slim Select Bay modules can become hot
with use. Be careful when removing the module.
S LIM S ELECT B AY
LATCH
DVD-ROM DRIVE
L OCK SCREW
DVD-ROM DRIVE
L OCK SCREW
