Toshiba Dynadock U10 - Manual (Page 24)

EN-24 User’s Manual
dynadock™
Windows Vista ® Operations
1. In the Analog Output section, select headphone.
(Sample Image) Select headphone
2. On the panel, click the 7.1 Virtual SPEAKER SHIFTER button to
enable the virtual multi-channel function. The icon will turn blue and a
mark will be shown in the rightside window when selected.
(Sample Image) 7.1 Virtual SPEAKER SHIFTER button
3. The button next to DSP Mode string allows you to enter the SHIFTER
control window.
(Sample Image) DSP button
Click on the Virtual Speaker Shifter button to open the Shifter controls.
See page 26 for the SHIFTER Control window sample image.
NOTE: In order to use the S/PDIF function in Windows Vista ® , select
Start > Control Panel > Hardware and Sound > Sound. In the
Playback tab, set the Digital Output as default device.
