User’s Manual 2-7
The Grand Tour
Front with the display open
The figure below shows the front of the computer with the display open.
To open the display, slide the display latch on the front of the computer and
lift the display up. Position the display at a comfortable viewing angle.
The front with the display open
Power Button
Stereo Speaker (Left)
Touch Pad Control Buttons
Display Screen
Stereo Speaker (Right)
Display Hinge
Display Hinge
System Indicators
Internet Button *
CD/DVD Button *
Touch Pad/
Dual Mode
Pad
AV Buttons *
Display
Screen
The full-color LCD displays high-contrast text and
graphics The computer’s LCD consist of one of below:
15.4" WXGA, 1280 horizontal × 800 vertical pixels.
15.4" WXGA-CSV, 1280 horizontal × 800 vertical pixels.
The computer has a Thin-Film Transistor (TFT) display.
When the computer operates on power through the AC
adaptor, the display screen’s image will be somewhat
brighter than when it operates on battery power. The
lower brightness level is intended to save battery power.
Display Hinge The display hinge holds the display screen at easy-to-
view angles.
Stereo
Speaker
The speaker emits sound generated by your software as
well as audio alarms, such as low battery condition,
generated by the system.
Touch Pad/
Dual Mode
Pad
Moves the pointer and selects or activates items on the
screen. Can be set to perform other mouse functions,
such as scrolling, selecting, and double-clicking.
