SilkWorm 4016 Hardware Reference Manual
Publication Number: 53-1000175-01
Removing and Replacing the SilkWorm 4016
4
The following figure details the generic process for removing an SFP from a port.
5.
Squeeze the release lever latch to release the SilkWorm 4016.
SFP
Bale
3
1
Cable
Release
2
SFP
4
R
10
11
Squeeze
Squeeze
