3-2 SilkWorm 4016 Hardware Reference Manual
Publication Number: 53-1000175-01
Configuring the SilkWorm 4016
3
Creating a Serial Connection
To create a serial connection to the SilkWorm 4016 you need to connect to the serial port of the blade
server chassis’ management module.
When using HyperTerminal with the Microsoft Windows 2000 operating system, ensure that you have
Windows 2000 Service Pack 2 or later installed. The arrow keys function properly in HyperTerminal’s
VT100 emulation with Windows 2000 Service Pack 2.
1. Connect the null modem cable to the serial port on the management module and to the client
system.
2. Click the Start button, point to Programs > Accessories > Communications, and then click
HyperTerminal.
3. Enter a name for the new connection, select an icon, and then click OK.
4. From the Connect to drop-down menu, select an available COM port, and then click OK.
After you select an available COM port, the COM port properties window appears.
5. Configure the port with the following settings:
6. Click OK.
The management application displays a login screen on the console monitor.
7. Log into the management module using your administrative user name and password.
For details about setting up the terminal emulation with the correct connection and login information,
refer to the blade server chassis documentation.
Note
All versions of the Microsoft Windows operating system include Hilgraeve's HyperTerminal terminal
emulation software. However, the included version does not provide many functions required during
console redirection. Either upgrade to HyperTerminal Private Edition 6.3, or select new terminal
emulation software.
The examples in this section assume that you have upgraded to Hilgraeve's HyperTerminal Private
Edition 6.3. (Only Hilgraeve's HyperTerminal Private Edition 6.3 using Windows Server 2003 is
supported.) If you are using other terminal emulation software, see the documentation for that software.
Bits per second 115200
Data bits 8
Parity None
Stop bits 1
Flow control None
Properties VT100 for Emulation mode
Terminal keys
1
1. Ensure that the setting is not set to Windows keys
Function, Arrow, and Ctrl
