SilkWorm 4016 Hardware Reference Manual 2-1
Publication Number: 53-1000175-01
Chapter
2
Installing the Brocade SilkWorm 4016
This chapter provides the following information:
• “Unpacking the SilkWorm 4016” on page 2-1
• “Preparing the Blade Server for the SilkWorm 4016” on page 2-2
• “Inserting a SilkWorm 4016 into the Chassis” on page 2-2
Unpacking the SilkWorm 4016
To remove the SilkWorm 4016 from its shipping package:
1. Open the shipping box and inspect the contents, making sure that nothing is missing or damaged.
Do not insert a damaged switch into the PowerEdge chassis. If the SilkWorm 4016 appears to be
damaged, contact your sales representative before proceeding.
2. Remove the cardboard accessory tray that sits on top of the SilkWorm 4016.
This tray contains the documentation, regulatory statements, product information guide, and
Documentation CD.
3. Remove the switch from the box.
The protective foam ends will slide out with the switch.
4. Remove the foam ends from the switch.
5. Be sure that you have taken the necessary precautions for electrostatic sensitivity; then, break the
seal warning.
6. Slide the SilkWorm 4016 out of the antistatic sleeve and inspect it carefully for any obvious defects
or shipping damage.
