SilkWorm 4016 Hardware Reference Manual 1-3
Publication Number: 53-1000175-01
Switch Characteristics
1
Switch Characteristics
This chapter describe the physical characteristics of the SilkWorm 4016.
Weight and Physical Dimensions
Table 1-1 lists the weight and physical dimensions of the SilkWorm 4016.
Memory
The memory installed in the SilkWorm 4016 is shown in Table 1-2 .
Additional Port Activation
Table 1-3 shows the base (included) ports as well as the additional 4 ports that can be activated by
installing an optional 4-port Ports-on-Demand (POD) license. For details about activating POD
licensing, see
“Activating Ports on Demand (POD)” on page 3-6
Table 1-1 Switch Specifications
SilkWorm 4016
Height 1.27 in (32.2 mm)
Width 5.13 in (130 mm)
Depth 10 in (254 mm)
Weight 2.32 lb — without media
Table 1-2 Memory Specifications
Memory Type Value
PowerPC 440GP processor 200 MHz
SDRAM 256 Mbytes - for system memory at 64 bits
wide with 8 ECC bits
Boot flash 4 MB
Compact flash 256 MB
SEEPROM 256 Kbit
Table 1-3 Ports available
Port Licensing External Ports Internal Ports
Base 10 through 13 0 through 7
POD 14, 15 8, 9
