Setting the AV input

You can connect AV components to the AV
input with an RCA cable.
Switch the AV input setting according to the
connected AV component.
For more details, refer to the installation man-
ual.
! Select TV to watch video of a TV tuner as

TELEVISION source.

! Select DVD to watch video of a connected

DVD player as

S-DVD source.

! Select EXT.V to watch video of a connected

video unit as

EXT source.

! Select AUX to watch video of an auxiliary

equipment as

AUX2 source.

! Select CAMRA to watch a rear view cam-

era video while you are backing your vehi-
cle.

Press FUNCTION to select V.IN.

Press c or d to select your desired set-

ting.

! OFF – No video component connected
! TV – TV tuner
! EXT.V – External video unit (such as

Pioneer products available in the future)

! DVD – DVD player/multi-DVD player
! AUX – Auxiliary equipment
! CAMRA – Rear view camera

# To watch video of AUX source, set auxiliary 2
setting on. For details, refer to Switching the aux-
iliary setting on the previous page.
# If AV system display (e.g., AVX-7600) is com-
bined with this unit, connect the rear view cam-
era to the AV system display. For details
concerning connection methods, refer to AV sys-
tem display

’s instruction manual. Also, V.IN set-

ting of this unit need not be

CAMRA.

Setting for rear view camera (back
up camera)

CAUTION

Pioneer recommends the use of a camera
which outputs mirror reversed images, other-
wise screen image may appear reversed.

You can install a rear view camera onto the AV
input and display a rear view camera video.
When the gear shift is in REVERSE (R) posi-
tion, the video automatically switches to a rear
view camera video. (For more details, consult
your dealer.)
! After you set up the rear view camera set-

ting, move the gear shift in REVERSE (R)
and confirm if a rear view camera video
can be shown on the display.

! If the display should be switched to a rear

view camera video by error while you are
driving forward, change the rear view cam-
era setting.

! When you select CAMRA in V.IN, you can

select

CAMRA.

Press FUNCTION to select CAMRA.

Press c or d to select an appropriate

setting.

! BAT – When the polarity of the connected

lead is positive while the gear shift is in RE-
VERSE (R) position

! GND – When the polarity of the connected

lead is negative while the gear shift is in
REVERSE (R) position
