Connections

02

11

En

gli

sh

6 Switch the TV to all the other tuned
channels, including the channel tuned for the
VCR, and check the picture quality.
If the picture quality is good, go to the Start-
ing up the first time
on page 12. If there is
a picture quality problem even though the
aerial is connected, follow the instructions
below after completing Starting up the first
time
on page 12.

1

Disconnect the aerial from the back of

the DTR.

2

Check to make sure the TV is tuned to

the channel selected for watching digital
programmes.

3

Press the

MENU button on the remote.

The HOME MENU screen is displayed.

Connecting to a digital audio device

Connect an optical digital audio cable (sold seperately) between the optical digital audio output
socket on the DTR and an optical digital input on a sampling rate converter-equipped stereo
system, AV amp, etc.

230V

VCR

TV

OPTICAL

AERIAL

50Hz

TV

Digital Terrestrial Receiver

Sampling rate

converter-equipped

stereo system,

AV amp, etc.

4

Select

Setup from the HOME MENU

screen,

Installation, and then RF Out-

put Channel using

5, ∞ and SELECT

buttons on the remote.

The default setting for this option, 43,

should be changed if there is interfer-
ence. Select a channel that is far from
43. Press the

MENU button (Exit) to exit

the menu and store the setting.

5

Repeat from Step 4 to check if the

picture quality improves.

• If a Dolby Digital encoded audio stream

is output and you have a Dolby Digital
decoder equipped external digital audio
device, change your digital audio output
settings in User Preferences, Digital
Audio Out
. (See page 30.)

• If the external digital audio device does

not support the sampling rate at which
the digital audio is being broadcast, no
audio will be heard.

“Dolby” and the double-D symbol are trade-
marks of Dolby Laboratories.
