Scanning 2
C550 2-60
Entering addresses directly
Using the control panel to directly type in the destination address when
scanning is called “direct input”.
Settings can be specified for the following.
Detailed Settings
1
Press the [Fax/Scan] key
in the control panel.
The Fax/Scan mode
screen appears.
Parameter Description
Host Name Specify the host name or IP address for the destination. Type using
the keyboard that appears, and then touch [OK].
File Path Specify the path to the destination folder. Type using the keyboard
that appears, and then touch [OK].
User Name Type in the user name used to log on, and then touch [OK].
Password Specify the password. Type using the keyboard that appears, and
then touch [OK].
Parameter Description
Port Number Type in the port number.
PASV Select whether or not the PASV (passive) mode is used. Touch [Yes]
or [No].
Proxy Select whether or not a proxy server is used. Touch [Yes] or [No].
