Duplex Option 106
5
Attach the duplex option to the
printer.
a Hook the two tabs at the bottom
of the duplex option onto the
notches on the right side of the
printer.
b Push the duplex option toward the printer until it clicks on the top.
c While still supporting the duplex
unit, carefully open the right-side
door, and then check that the tabs
on the duplex unit are correctly
hooked onto the printer.
Attention
If the duplex option is released
before it is secured with the
screws, it may fall and break.
Be sure to keep the duplex
option supported until the
screws are tightened.
d Open the duplex option’s cover
and tighten the two thumbscrews
on the duplex option to secure the
unit to the printer.
e Close the duplex option’s cover.
