ATTO Technology Inc. Diamond Storage Array Installation and Operation Manual
5.4.1 ExpressNAV Pages
Each page in the ATTO ExpressNAV interface provides information and/or configuration parameters
based on a specific topics. Each page can be reached through the menu on the left hand side of each
page.
Status
Contains general array information.
• Unit Information including Vendor ID, Product
ID, Firmware Revision and Serial Number
• Environmental Information
• World Wide Identifiers including Node Names
and Port Names
• Host Interface Card Status
• Fan
Status
• Power Supply Status
• Storage Status including ATA Disk Errors and
Logical Unit Conflicts
Ethernet
Configures the Ethernet port.
• IP Address
• IP Gateway
• IP Subnet Mask
• Ethernet
Speed
• Use DHCP
Refer to Ethernet Access: Telnet and SNMP Protocols
on page 23 and Ethernet Commands on page 35 for
details.
SNMP
Remote system monitoring is available using
Simple Network Management Protocol (SNMP).
• Updates
• Traps
• Trap Recipient IP Addresses
Refer to Ethernet Commands on page 35 and Ethernet
Access: Telnet and SNMP Protocols on page 23 for
details on each parameter.
Serial Port
Contains the necessary information to configure
the serial port including baud rate and echo.
Refer to Serial Port Access on page 21 and Serial Port
Configuration Commands on page 39 for more
information on each parameter.
Fibre Channel
Contains parameters and information to manage
the Fibre Channel port.
• Data rate
• Full duplex mode
• Connection mode
Refer to Connecting a Fibre Channel Array on page 11
and Fibre Channel Configuration Commands on page
37 for more information.
Storage Management
Shows information about the drives and their
status. Information includes
• Sled Number
• Capacity of each sled
• Number
of errors
• Configuration type (JBOD, RAID5, etc.)
• Virtual
ID
You may place sleds on or off line by selecting or
de-selecting a check box.
Refer to Determining Drive and Sled Designations on
page 15 and Drive Configuration Commands on page
45 for more information.
Once you open this page, several other
configuration pages are available on the menu on
the left hand side of the page.
RAID
Contains the necessary information and
parameters to configure RAID groups.
Information provided includes
• Type of configuration (RAID5, JBOD, etc.)
• Virtual Disk ID
• State of sleds
• Capacity of sleds
• Interleave values
You may change the configuration of these
parameters
• Configuration Type (JBOD, RAID5)
• Number of Groups (when applicable)
• Interleave
• Striping method (sled or drive)
• Rebuild priority
