Z/P Series Hardware Maintenance Manual
Figure 14. Removal steps of LCD unit
Z500/P500
Remove the five screws
1
.
Step Screw (quantity)
Color Torque
M2.5 × 6 mm, flat-head, nylok-coated (5)
Black 8.03 kg-cm
’
M2 × 2 mm, flat-head, nylok-coated (1) (Z400)
Black 1.85+/-0.15 kgf*cm
