1030 base cover – Lenovo IdeaPad P500 Touch Notebook User Manual
Page 43

39
Lenovo Z/P Series
1030 Base cover
For access, remove this FRU:
• “1010 Keyboard” on page 33
• “1020 Optical drive” on page 36
Figure 3. Removal steps of base cover
Z400
Remove the four screws
1
.
1
1
1
Step
Screw (quantity)
Color
Torque
1
M2.5 × 6 mm, flat-head, nylok-coated (4)
Black
3.0+/-0.3 kgf*cm
