4-28
Section 4 OPERATING INSTRUCTIONS
1 AND bit shift count for the mark ratio
2 External error injection
3 Floppy disk format type
4 Alternate pattern A/B switching timing
SW6 SW5
Bit shift number for Alternate A/B
0 0 : 0 BIT
5, 6
select timing
0 1 : 1 BIT
1 0 : 2 BIT
1 1 : 3 BIT
4.6 Functions of the FUNCTION Switch
Table 4.6-1 lists the functions of the FUNCTION switch on the rear of the instrument.
Table 4.6-1 Functions of the FUNCTION Switch
SW Item Function
Note: The FUNCTION switch on the rear panel is covered with the panel and fasten with screws to decrease the radio
active radiation.
To change the FUNCTION switch, remove the panel for the setting.
.
0: 1 bit
1: 3 bits
0: OFF
1: ON
0: 1440/720KB
1: 1232/640KB
0: INTERNAL
1: EXTERNAL
