3-5
3.2 REAR PANEL
GPIB address Dip switch
Sets the address when the instrument is remotely controlled by GPIB. It is usually set to .
SYSTEM CONTROL switch
When this switch is set to ' ON ' , this instrument control other one.
GPIB connector
Connector for GPIB cable. (The cable is connected when the instrument is remotely controlled by GPIB.)
FUNCTION Dip switch
It is possible to select functions noted rear panel.
Error ADDITION CH
Selects which of the 32 channels an error is to be added.
INTERNAL SYNTHESIZER
Internal CLOCK output connector when OPTION 01 installed.
OUTPUT
CLOCK INPUT
Clock signal input connector. (When the internal synthesizer is used, this connector is connected to the INT. SYNTHE.
OUTPUT connector.)
STD 10 MHz
When OPTION 01 (internal synthesizer) is used, synthesizes the other signals and the internal synthesizer.
10 MHz TTL level
1/8 SPEED output connector
1/8 DATA and 1/8 CLOCK output connector (ECL level)
Note: When OPTION 03 (1/4 SPEED OUTPUT) is installed, this connector becomes the 1/4 DATA, 1/4 CLOCK output
connector.
GATING signal input connector
0/-1 V 50
Ω
Alternate pattern A/B switching
ECL level 50
Ω
Timing I-O connector
Error addition control connector
0/-1 V 50
Ω
Power inlet
Functional earth terminal
Connected to the earth terminal of an instrument connected to this instrument.
Fuse holder
ш ш ш ш ш
5 4 3 2 1
