3.1 FRONT PANEL
Power switch
When , the power is turned on and the LED goes on.
When , the power is turned off.
LOCAL key
Switches from the GPIB REMOTE mode (LED lit) to the LOCAl (key operation possible) mode.
In GPIB REMOTE mode, all the keys other than the power switch and LOCAL key are ineffective.
PANEL LOCK key
Panel lock (LED lit) disables all the keys other than the POWER switch and the PANEL LOCK key.
SYNC OUTPUT keys
Select the type of SYNC OUTPUT.
1/64 CLOCK: Outputs a CLOCK divided by 64.
FIXED POSITION: Outputs a synchronization pulse at a fixed position to the output pattern.
VARIABLE POSITION: Shifts the synchronization pulse output position in 16 bits unit.
Output connectors
DATA, DATA
Output.
CLOCK1, CLOCK1
Complementary CLOCK output.
CLOCK2
Auxiliary clock output.
DUMMY
Connects the unused side of the complementary output.
Note:
If the unused side of the complementary output is opened, the output waveform on the side
used will be degraded.
OUTPUT condition block
Sets the output level, offset and termination conditions.
PATTERN setting block
Sets the generated pattern type, logic, etc.
Performs error addition.
Frequency setting block
Sets the frequency when OPTION 01 installed.
Floppy disk drive
Saves the set pattern and other conditions to a floppy disk.
