Set-Up Guide
STEP 2: Audio Conferencing
Plug Cable A (single RCA to double RCA) single RCA connector into Fusion
Base Station RCA port, and then plug the double RCA
connectors into the powered speakers or a powered amplifier. Plug speakers
into wall outlet.
Plug one end of Cable B, the phone line cable, into the Fusion Base Station
, plug other end into phone jack. You may also plug a phone into the
RJ11 , You may then dial with the remote control or the phone.
If you ordered 01-8FUSION(EU)-62 6 omni tabletops/2 wearable
microphones or 01-4FUSION(EU)-31 3 omni tabletops/1 wearable
microphone. You are all set to go! Take out the Wireless Microphones,
unmute them by pressing the mute button on the microphone and the
system
is ready for a conference!
If you selected your microphones separately with the 01-8FUSION(EU)-NM
or 01-4FUSION(EU)-NM Fusion part numbers, you must first establish a
connection between your microphones to the Fusion Base Station. This is
called “pairing”. Refer to page 9.
STEP 2: Video Conferencing
You must have the audio output going
f rom the Fusion Base station directly to
the speakers used by the video-conferencing station. Plug Cable A (single RCA
to double RCA) single RCA connector into Fusion Base Station
RCA port and then plug the double RCA connectors into the speakers or
monitor.
Once you have configured your video-conferencing station as shown on pages
11-17, then:
If you ordered 01-8FUSION-62 6 omni tabletops/2 wearable microphones or
01-4FUSION-31 3 omni tabletops/1 wearable microphone. You are all set to
go! Take out the Wireless Microphones, unmute them by pressing the mute
button on the microphone and the
system is ready for a conference!
If you selected your microphones separately with the 01-8FUSION-NM or 01
-4FUSION-NM Fusion part numbers, you must first establish a connection
between your microphones to the Fusion Base Station. This is called “pairing”.
Refer to page 9.
Page 8
