Remote IR Sensor
Setting the Remote IR Sensor Option
Front Panel IR Sensor (default)
If the Fusion Base Station is within view of the Remote Control, the front panel
IR Sensor will accept all Remote Control functions. DIP switch #7 is OFF (page
18).
Remote IR Sensor
If the Fusion Base Station is in a cabinet and behind a door (non-metal), the
front panel IR Sensor cannot work. The Remote IR Sensor cable (part number:
07-IRREMO-01) must be used to position the Fusion IR Sensor outside of the
cabinet. Plug the serial plug end into the IR Remote connector on the back
panel of the Fusion Base Station (page 9), bring IR Sensor end out of cabinet, and
secure with Velcro. then set DIP switch #7 to ON (page 18).
NOTE: The Fusion system must be powered off and back on for any
DIP Switch changes to take effect.
