4-20 MegaCLI Command Tool
Version 2.0 Copyright © 2006 by LSI Logic Corporation. All rights reserved.
4.9.9 Prepare Unconfigured Physical Disk Drives for Removal
Use the command in Table 4.35 to prepare an unconfigured physical disk
drive(s) for removal from the selected adapter(s).
4.9.10 Display Number of Physical Disk Drives
Use the command in Table 4.36 to display the total number of physical
disk drives attached to an adapter. Drives can be attached directly or
through enclosures.
4.9.11 Display List of Physical Drives
Use the command in Table 4.37 to display a list of the physical drives
connected to the selected adapter(s).
Description Replaces the configured physical disk drives, then starts an automatic rebuild. The
specified arrayIndex and row must be a missing drive.
Table 4.34 Replace Configured Disk Drives and Start Automatic Rebuild (Cont.)
Table 4.35 Prepare Unconfigured Physical Disk Drives for Removal
Syntax CmdTool –PDPrpRmv [-Undo] –PhysDrv[E0:Sn....] -aN|-a0,1,2|-aALL
Description Prepares unconfigured physical drive(s) for removal. The drive is spun down, and
the drive state is set to unaffiliated, which marks it as offline even though it is not a
part of configuration.
The -Undo option undoes this operation, and the firmware marks this physical disk
as Unconfigured-Good.
Table 4.36 Display Number of Physical Disk Drives
Syntax CmdTool –PDGetNum –aN|-a0,1,2|-aALL
Description Displays the total number of physical disk drives attached to an adapter. The return
value is the number of physical disk drives.
Table 4.37 Display List of Physical Drives
Syntax CmdTool –PDList –aN|-a0,1..|-aAll
Description Displays information about all physical disk drives connected to the selected
adapter(s). This includes information such as the drive type, size, serial number, and
firmware version. For SAS devices, this includes additional information such as the
SAS address.
