25
MS-7623
Cell Menu
Current CPU/DraM Frequency
it shows the current frequency of CPU/Memory. read-only.
CPU Specifications
Press to enter the sub-menu and it displays the informations of installed
CPU.
aMD Cool’n’Quiet
the Cool’n’Quiet technology can effectively and dynamically lower CPU speed
and power consumption.
iMPOrtant
to ensure that Cool’n’Quiet function is ac-
tivated and will be working properly, it is
required to double confirm that:
run BiOS Setup, and select Cell Menu.
Under Cell Menu, find aMD Cool’n’Quiet,
and set this item to “Enabled”.
Enter Windows, and select [Start]->[Set-
tings]->[Control Panel]->[Power Options].
Enter Power Options Properties tag, and
select Minimal Power Management under
Power schemes.
*
*
adjust CPU FSB Frequency (Mhz)
this item allows you to adjust the CPU FSB frequency.
adjust CPU ratio
this item is used to adjust CPU clock multiplier (ratio). it is available only when the
processor supports this function.
adjusted CPU Frequency (Mhz)
it shows the adjusted CPU frequency. read-only.
adjust CPU-nB ratio
this item is used to adjust CPU-nB ratio.
adjusted CPU-nB Frequency (Mhz)
it shows the adjusted CPU-nB frequency. read-only.
EC Firmware
this item allows you to select the EC Firmware for advanced Clock Calibration.
For unlocking the additional cores, you could set it [Special] and then set advanced
Clock Calibration [auto] in order to be able to activate the processor cores.
advanced Clock Calibration
this item is for overclock. Setting to [Enabled] allows you to set the CPU ratio
higher. it is available only when the processor supports this function.
MultiStep OC Booster
this item is used to avoid the BiOS might crash with overclocking. Setting to
[Disabled] disable this item, apply OC settings during POSt. [Mode 1] Slight OC
during POSt and then apply full OC when loading the OS. [Mode 2] load the OS
then apply the OC settings.
MEMOrY-Z
Press to enter the sub-menu, select a item form DiMM list and enter to
read the memory SPD informations.
advance DraM Configuration
Press to enter the sub-menu.
DraM timing Mode
Selects whether DraM timing is controlled by the SPD (Serial Presence De-
tect) EEPrOM on the DraM module. Setting to [auto By SPD] enables DraM
timings and the following related items to be determined by BiOS based on the
configurations on the SPD. Selecting [Manual] allows users to configure the
DraM timings and the following related items manually.
CaS latency (Cl)
When the DraM timing Mode sets to [Manual], the field is adjustable. this
controls the CaS latency, which determines the timing delay (in clock cycles)
before SDraM starts a read command after receiving it.
trCD
When the DraM timing Mode sets to [Manual], the field is adjustable. When
DraM is refreshed, both rows and columns are addressed separately. this
setup item allows you to determine the timing of the transition from raS (row
address strobe) to CaS (column address strobe). the less the clock cycles, the
