Page 58

DS271F5

CS8900A

Crystal LAN™ Ethernet Controller

CIRRUS LOGIC PRODUCT DATASHEET

001000

These bits provide an internal address used by the CS8900A to identify this as the Transmitter

Event Register.

Loss-of-CRS

If the CS8900A is transmitting on the AUI and doesn't see Carrier Sense (CRS) at the end of

the preamble, there is a Loss-of-Carrier error and this bit is set. If Loss-of-CRSiE (Register 7,
TxCFG, Bit 6) is set, there is an interrupt.

SQEerror

At the end of a transmission on the AUI, the CS8900A expects to see a collision within 64 bit

times. If this does not happen, there is an SQE error and this bit is set. If SQEerroriE (Register
7, TxCFG, Bit 7) is set, there is an interrupt.

TxOK

This bit is set if the last packet was completely transmitted (Jabber (Bit A), out-of-window-colli-

sion (Bit 9), and 16Coll (Bit F) must all be clear). If TxOKiE (Register 7, TxCFG, Bit 8) is set,
there is an interrupt.

Out-of-Window

This bit is set if a collision occurs more than 512 bit times after the first bit of the preamble. When

this occurs, the CS8900A forces a bad CRC and terminates the transmission. If Out-of-window-
iE (Register 7, TxCFG, Bit 9) is set, there is an interrupt

Jabber

If the last transmission is longer than 26 msec, then the packet output is terminated by the jab-

ber logic and this bit is set. If JabberiE (Register 7, TxCFG, Bit A) is set, there is an interrupt.

#-of-TX-collisions

These bits give the number of transmit collisions that occurred on the last transmitted packet.

Bit B is the LSB. If AnycolliE (Register 7, TxCFG, Bit B) is set, there is an interrupt when any
collision occurs.

16coll

This bit is set if the CS8900A encounters 16 normal collisions while attempting to transmit a

particular packet. When this happens, the CS8900A stops further attempts to send that packet.
If 16colliE (Register 7, TxCFG, Bit F) is set, there is an interrupt.

Reset value is:

0000 0000 0000 1000

Notes: 1.In any event register, like TxEvent, all bits are cleared upon readout. The host is responsible for

processing all event bits.
2.TxOK (Bit 8) and the Number-of-Tx-Collisions (Bits E-B) are used in normal packet transmission.All
other bits (6, 7, 9, A, and F) give the status of abnormal transmit operation.

4.4.11 Register 9: Transmit Command Status

(TxCMD, Read-only, Address: PacketPage base + 0108h)

This register contains the latest transmit command which tells the CS8900A how the next packet should be sent.
The command must be written to PacketPage base + 0144h in order to initiate a transmission. The host can read
the command from register 9 (PacketPage base + 0108h). See Section 5.6 on page 99.

001001

These bits provide an internal address used by the CS8900A to identify this as the Transmit

Command Register. When reading this register, these bits will be 001001, where the LSB cor-
responds to Bit 0.

TxStart

This pair of bits determines how many bytes are transferred to the CS8900A before the MAC

starts the packet transmit process.

TxStart

001001

TxPadDis

InhibitCRC

Onecoll

Force
