Page 109
DS271F5
109
CS8900A
Crystal LAN™ Ethernet Controller
CIRRUS LOGIC PRODUCT DATASHEET
The input pins not included in this test are:
After the Input Cycle is complete, one more cy-
cle of AEN returns all digital output pins and bi-
directional pins to a high-impedance state.
6.2.3 Continuity Cycle
The combination of a complete Output Cycle,
a complete Input Cycle, and an additional AEN
cycle is called a Continuity Cycle. Each Conti-
nuity Cycle lasts for 85 AEN clock cycles. The
first Continuity Cycle can be followed by addi-
tional Continuity Cycles by keeping TEST low
and continuing to cycle AEN. When TEST is
driven high, the CS8900A exits Boundary
Scan mode and AEN is again used as the ISA-
bus Address Enable.
Figure 32 shows a complete Boundary Scan
Continuity Cycle.
Figure 33 shows Boundary Scan timing.
DMACK1
14
IOR
61
DMACK0
16
IOW
62
SD08-SD15 27-24, 21-18
SD0 - SD7
65-68, 71-74
MEMW
28
RESET
75
MEMR
29
SLEEP
77
Pin Name
Pin #
Pin Name
Pin #
AEN
63
Cl-
82
TEST
76
RXD+
91
Dl+
79
RXD-
92
Dl-
80
XTAL1
97
Cl+
81
Table 42.
Pin Name
Pin #
Pin Name
Pin #
Table 41.
(continued)
