CS5510/11/12/13
6 DS337F4
DYNAMIC CHARACTERISTICS
ABSOLUTE MAXIMUM RATINGS
(V- = 0 V) (See Note 15.)
Notes: 15. All voltages with respect to V-.
16. V+ and V- must satisfy 0.0V ≤ {(V+) - (V-)} ≤ +6.0 V.
17. Applies to all pins including continuous overvoltage conditions at the analog input (AIN) pins.
18. Transient current of up to 100 mA will not cause SCR latch-up. Maximum input current for a power
supply pin is ±50 mA.
19. Total power dissipation, including all input currents and output currents.
WARNING: Operation at or beyond these limits may result in permanent damage to the device.
Normal operation is not guaranteed at these extremes.
Parameter Symbol Ratio Units
Modulator Sampling Frequency CS5510/12
CS5511/13
f
s
f
s
SCLK/4
f
osc
/4
Hz
Hz
Output Word Rate CS5510/12
CS5511/13
OWR
OWR SCLK/612
f
osc
/612
Sps
Sps
Filter Settling Time to 1/2 LSB (Full Scale Step) t
s
4/OWR s
Parameter Symbol Min Typ Max Unit
DC Power Supplies (Note 16)
Positive
Negative
V+
V-
-0.3
-6.0 -
- +6.0
+0.3 V
V
Input Current, Any Pin Except Supplies (Notes 17 and 18) I
IN
- - ±10 mA
Output Current I
OUT
- - ±25 mA
Package Power Dissipation (Note 19) PDN - - 400 mW
Analog Input Voltage AIN pins V
INA
(V-)+(-0.3) - (V+)+0.3 V
Digital Input Voltage V
IND
( V- )+(-0.3) - (V+)+0.3 V
Ambient Operating Temperature T
A
-40 - +85 °C
Storage Temperature T
stg
-65 - +150 °C
