CS5466
DS659F2
9
ABSOLUTE MAXIMUM RATINGS
WARNING: Operation at or beyond these limits may result in permanent damage to the device.
Normal operation is not guaranteed at these extremes
.
Notes:
16.
VA+ and AGND must satisfy {(VA+) - (AGND)}
+ 6.0 V.
17.
VD+ and AGND must satisfy {(VD+) - (AGND)}
+ 6.0 V.
18.
Applies to all pins including continuous over-voltage conditions at the analog input pins.
19.
Transient current of up to 100 mA will not cause SCR latch-up.
20.
Maximum DC input current for a power supply pin is ±50 mA.
21.
Total power dissipation, including all input currents and output currents.
Parameter
Symbol Min Typ
Max
Unit
DC Power Supplies
Positive Digital
Positive Analog
VD+
VA+
-0.3
-0.3
-
-
+6.0
+6.0
V
V
Input Current, Any Pin Except Supplies
I
IN
-
-
±10
mA
Output Current, Any Pin Except VREFOUT
I
OUT
-
-
100
mA
Power Dissipation
(Note 21)
P
D
-
-
500
mW
Analog Input Voltage
All Analog Pins
V
INA
- 0.3
-
(VA+) + 0.3
V
Digital Input Voltage
All Digital Pins
V
IND
-0.3
-
(VD+) + 0.3
V
Ambient Operating Temperature
T
A
-40
-
85
°C
Storage Temperature
T
stg
-65
-
150
°C
