CS5466
DS659F2
7
DIGITAL CHARACTERISTICS
•
Min / Max characteristics and specifications are guaranteed over all operating conditions.
•
Typical characteristics and specifications are measured at nominal supply voltages and TA = 25 °C.
•
VA+ = 5 V ±5% VD+ = 3.3 V ±5% or 5 V ±5%; AGND = DGND = 0 V. All voltages with respect to 0 V.
•
MCLK = 4.096 MHz
Notes:
7.
All measurements performed under static conditions.
8.
If external MCLK is used, then the duty cycle must be between 45% and 55% to maintain this specification.
9.
The frequency of CPUCLK is equal to MCLK.
10.
V
OL
and V
OH
are
not specified under this condition.
Parameter
Symbol Min Typ
Max
Unit
Master Clock Characteristics
Master Clock Frequency
Internal Gate Oscillator
MCLK
3
4.096
5
MHz
Master Clock Duty Cycle
-
40
-
60
%
CPUCLK Duty Cycle
(Note 8 and 9)
-
40
-
60
%
Filter Characteristics
High-pass Filter Corner Frequency
-3 dB
-
-
0.125
-
Hz
Input/Output Characteristics
High-level Input Voltage
XIN
RESET
V
IH
(VD+) - 0.5
0.8
VD+
-
-
-
-
V
V
Low-level Input Voltage (VD = 5 V)
XIN
RESET
V
IL
-
-
-
-
1.5
0.2
VD+
V
V
Low-level Input Voltage (VD = 3.3 V)
XIN
RESET
V
IL
-
-
-
-
0.3
0.2
VD+
V
V
High-level Output Voltage (except XOUT)
I
out
= +5 mA
V
OH
(VD+) - 1.0
-
-
V
Low-level Output Voltage (except XOUT)
I
out
= -5 mA
V
OL
-
-
0.4
V
Input Leakage Current
I
in
-
±1
±10
µA
Digital Output Pin Capacitance
C
out
-
5
-
pF
Drive Current FOUT, E1, E2, NEG
I
DR
-
50
-
mA
