CS5466
DS659F2
5
3. CHARACTERISTICS & SPECIFICATIONS
RECOMMENDED OPERATING CONDITIONS
ANALOG CHARACTERISTICS
•
Min / Max characteristics and specifications are guaranteed over all operating ponditions.
•
Typical characteristics and specifications are measured at nominal supply voltages and TA = 25 °C.
•
VA+ = 5 V ±5% VD+ = 3.3 V ±5% or 5 V ±5%; AGND = DGND = 0 V. All voltages with respect to 0 V.
•
MCLK = 4.096 MHz
Notes:
1.
Applies when the HPF option is enabled
2.
Applies before system calibration. Specified as a percentage of full scale (FS).
Parameter
Symbol Min Typ
Max
Unit
Positive Digital Power Supply
VD+
3.135
5.0
5.25
V
Positive Analog Power Supply
VA+
4.75
5.0
5.25
V
Voltage Reference
VREFIN
-
2.5
-
V
Specified Temperature Range
T
A
-40
-
+85
°C
Parameter
Symbol Min Typ
Max
Unit
Analog Inputs (Current Channel)
Differential Input Range
(Gain = 10)
[(I
IN
+)-(I
IN
-)]
(Gain = 50)
(Gain = 100)
(Gain = 150)
I
IN
-
-
-
-
±250
±50
±25
±16.7
-
-
-
-
mV
mV
mV
mV
Input Capacitance
(All Gain Ranges)
C
in
I
-
25
-
pF
Effective Input Impedance
(All Gain Ranges)
Z
in
I
30
-
-
k
Analog Inputs (Voltage Channel)
Differential Input Range
[(V
IN
+)-(V
IN
-)]
V
IN
-
-
±250
mV
Input Capacitance
C
in
V
-
0.2
-
pF
Effective Input Impedance
Z
in
V
2
-
-
M
Accuracy (Energy Outputs)
Active Energy Linearity
All Gain ranges
Input Range 0.1% - 100%
-
-
±0.1
-
%
Full-scale Error
(Note 2)
-
-
4.0
-
%FS
Offset Error
(Note 2)
-
-
0.06
-
%FS
