CS5463

8

DS678F3

ANALOG CHARACTERISTICS

(Continued)

Notes: 3. Applies before system calibration.

4. All outputs unloaded. All inputs CMOS level.

5. Measurement method for PSRR: VREFIN tied to VREFOUT, VA+ = VD+ = 5 V, a 150 mV

(zero-to-peak) (60 Hz) sinewave is imposed onto the +5 V DC supply voltage at VA+ and VD+ pins. The
“+” and “-” input pins of both input channels are shorted to AGND. Then the CS5463 is commanded to
continuous conversion acquisition mode, and digital output data is collected for the channel under test.
The (zero-to-peak) value of the digital sinusoidal output signal is determined, and this value is converted
into the (zero-to-peak) value of the sinusoidal voltage (measured in mV) that would need to be applied
at the channel’s inputs, in order to cause the same digital sinusoidal output. This voltage is then defined
as Veq. PSRR is then (in dB)

:

6. When voltage level on PFMON is sagging, and LSD bit = 0, the voltage at which LSD is set to 1.

7. If the LSD bit has been set to 1 (because PFMON voltage fell below PMLO), this is the voltage level on

PFMON at which the LSD bit can be permanently reset back to 0.

Parameter

Symbol Min

Typ

Max

Unit

Analog Inputs (Voltage Channel)

Differential Input Range

[(VIN+) - (VIN-)]

VIN

- 500

-

mV

P-P

Total Harmonic Distortion

THD

65

75

-

dB

Crosstalk with Current Channel at Full Scale (50, 60 Hz)

-

-70

-

dB

Input Capacitance

All Gain Ranges

IC

-

0.2

-

pF

Effective Input Impedance

EII

2

-

-

M

Noise (Referred to Input)

N

V

-

140

-

µV

rms

Offset Drift (Without the High Pass Filter)

OD

-

16.0

-

µV/°C

Gain Error

(Note 3)

GE

-

±3.0

%

Temperature Channel

Temperature Accuracy

T

-

±5

-

°C

Power Supplies

Power Supply Currents (Active State)

I

A+

I

D+

(VA+ = VD+ = 5 V)

I

D+

(VA+ = 5 V, VD+ = 3.3 V)

PSCA
PSCD
PSCD

-
-
-

1.1
2.9
1.7

-
-
-

mA
mA
mA

Power Consumption

Active State (VA+ = VD+ = 5 V)

(Note 4)

Active State (VA+ = 5 V, VD+ = 3.3 V)

Stand-by State

Sleep State

PC

-
-
-
-

21

11.6

8

10

29

17.5

-
-

mW
mW
mW

µW

Power Supply Rejection Ratio

(50, 60 Hz)

(Note 5)

Voltage Channel
Current Channel

PSRR

45
70

-

65
75

-
-
-

dB
dB

PFMON Low-voltage Trigger Threshold

(Note 6)

PMLO

2.3

2.45

-

V

PFMON High-voltage Power-on Trip Point

(Note 7)

PMHI

-

2.55

2.7

V

PSRR

20

150
V

eq

----------

log

=
