CS5463
DS678F3 25
Register Page 1
Address RA[4:0] Name Description
0 00000 PulseWidth Energy Pulse Output Width
1 00001 Load
Min
No Load Threshold
2 00010 T
Gain
Temperature Sensor Gain
3 00011 T
off
Temperature Sensor Offset
Register Page 3
Address RA[4:0] Name Description
6 00110 VSAG
Duration
Voltage sag sample interval
7 00111 VSAG
Level
Voltage sag level
10 01010 ISAG
Duration
Current fault sample interval
11 01011 ISAG
Level
Current fault level
Note: For proper operation, do not attempt to write to unspecified registers.
5.16.6 Calibration
The CS5463 can perform system calibrations. Proper input signals must be applied to the current and voltage chan-
nel before performing a designated calibration.
CAL[4:0]* Designates calibration to be performed
01001 = Current channel DC offset
01010 = Current channel DC gain
01101 = Current channel AC offset
01110 = Current channel AC gain
10001 = Voltage channel DC offset
10010 = Voltage channel DC gain
10101 = Voltage channel AC offset
10110 = Voltage channel AC gain
11001 = Current and Voltage channel DC offset
11010 = Current and Voltage channel DC gain
11101 = Current and Voltage channel AC offset
11110 = Current and Voltage channel AC gain
*For proper operation, values for CAL[4:0] not specified should not be used.
B7 B6 B5 B4 B3 B2 B1 B0
1 1 0 CAL4 CAL3 CAL2 CAL1 CAL0
