DS691F2 7
CS4350
2 CHARACTERISTICS AND SPECIFICATIONS
2.1 Recommended Operating Conditions
GND = 0 V; all voltages with respect to ground.
2.2 Absolute Maximum Ratings
GND = 0 V; all voltages with respect to ground (Note 1) .
Notes: 1. Operation beyond these limits may result in permanent damage to the device.
Normal operation is not guaranteed at these extremes.
2. Any pin except supplies.
RST 24
Reset (Input) - When pulled low, device will power down and reset all internal registers to their default
settings.
Control Port Definitions
AD1/CDOUT
1 Address Bit 1/Serial Control Data Out (I/O) - Chip address bit 1 in I²C Mode or data output in SPI Mode
AD0/CS 2 Address Bit 0/Chip Select (Input) - Chip address bit 0 in I²C Mode or Chip Select in SPI Mode
SDA/CDIN 3 Serial Control Data In (I/O) - Input/Output for I²C data. Input for SPI data
SCL/CCLK 4 Serial Control Port Clock (Input) - Serial clock for the control port interface
Stand-Alone Definitions
DIF0
DIF1
DIF2
1, 3, 4
Digital Interface Format (Input) - Defines the required relationship between the Left Right Clock, Serial
Clock, and Serial Audio Data
DEM 2
De-emphasis (Input) - Selects the standard 15 s/50 s digital de-emphasis filter response for
44.1 kHz sample rates
Table 1. Recommended Operating Conditions
Parameters Symbol Min Typ Max Units
DC Power Supply Analog power VA 4.75 5.0 5.25 V
3.14 3.3 3.46 V
Serial Audio Interface power VLS 1.35 3.3 5.25 V
Control Interface power VLC 3.14 3.3 5.25 V
Ambient Operating Temperature (Power Applied)
Commercial (-CZZ) T
A
-40 - +85 °C
Automotive (-DZZ) T
A
-40 - +105 °C
Table 2. Absolute Maximum Ratings
Parameters Symbol Min Max Units
DC Power Supply Analog power VA -0.3 6.0 V
Serial Audio Interface power VLS -0.3 6.0 V
Control Interface power VLC -0.3 6.0 V
Input Current (Note 2) I
in
- ±10 mA
Digital Input Voltage Serial Audio Interface V
IN-LS
-0.3 VLS+ 0.4 V
Control Interface V
IN-LC
-0.3 VLC+ 0.4 V
Ambient Operating Temperature (power applied) T
A
-55 125 °C
Storage Temperature T
stg
-65 150 °C
Pin Name # Pin Description
