2.9

Digital Characteristics

2.10 Power and Thermal Characteristics

Notes: 16. Current consumption increases with increasing Fs within the range of a speed mode. Variance between

speed modes is small. Typ and Max values are based on Fs = 48 kHz.

17. I

LS

measured with no external loading on pin 7 (RMCK).

18. I

LC

measured with no external loading on pin 2 (SDA).

19. Power-down mode is defined as RST pin = Low with all clock and data lines held static.
20. Valid with the recommended capacitor values on VFILT, VQ, and VBIAS+ as shown in the typical con-

nection diagram in

Figure 10

.

Table 9. Digital Characteristics

Parameters

Symbol Min Typ

Max

Units

High-Level Input Voltage

VLC or VLS = 5.0 V

V

IH

0.7•V

L

-

-

V

VLC or VLS = 3.3 V

V

IH

2.0

-

-

V

VLS = 2.5 V

V

IH

1.7

-

-

V

VLS = 1.5 V

V

IH

0.75•V

L

-

-

V

High-Level Input Voltage

VLC or VLS = 5.0 V

V

IL

-

-

0.35•V

L

V

VLC or VLS = 3.3 V

V

IL

-

-

0.8

V

VLS = 2.5 V

V

IL

-

-

0.7

V

VLS = 1.5 V

V

IL

-

-

0.25•V

L

V

Input Leakage Current

I

in

-

-

±10

A

Input Capacitance

-

8

-

pF

High Level Output Voltage (RMCK) I

O

= 2 mA (VLS



3.0V)

V

OH

VLS-1.0

-

-

V

Low Level Output Voltage (RMCK) I

O

= -2 mA (VLS



3.0V)

V

OL

-

-

0.4

V

RMCK Output Load Drive

-

-

10

pF

Maximum MUTEC Drive Current

-

2

-

mA

MUTEC High-Level Output Voltage

V

OH

-

VA

-

V

MUTEC Low-Level Output Voltage

V

OL

-

0

-

V

Table 10. Power and Thermal Characteristics

Parameters

Symbol

Min

Typ

Max

Units

Power Supply Current - Normal Operation

(Note 16)

VA= 5.0 V

I

A

-

28

34

mA

VA= 3.3 V

I

A

-

24

29

mA

VLS

= VLC

=5.0 V

(Note 17)

I

LS

-

4

6

mA

VLS

= VLC

=3.3 V

(Note 17)

I

LS

-

2

5

mA

VLS

= VLC

= 5.0 V

(Note 18)

I

LC

-

14

18

mA

VLS

= VLC

= 3.3 V

(Note 18)

I

LC

-

14

18

mA

Power Supply Current - Power-Down State

(Note 19)

VA, VLS

,

VLC

I

pd

-

100

-

A

Power Dissipation - Normal Operation

(Note 16)

VA = VLC= VLS = 5.0 V

-

230

290

mW

VA = VLC= VLS = 3.3 V

-

132

171

mW

Power Dissipation - Power-Down State

(Note 19)

VA = VLC= VLS = 5.0 V

-

0.5

-

mW

VA = VLC= VLS = 3.3 V

-

0.33

-

mW

Power Supply Rejection Ratio

(Note 20)

(1 kHz)

PSRR

-

60

-

dB

(60 Hz)

PSRR

-

50

-

dB
