40 DS604F2
CS42426
13h Vol. Control
A3 A3_VOL7 A3_VOL6 A3_VOL5 A3_VOL4 A3_VOL3 A3_VOL2 A3_VOL1 A3_VOL0
page 53
default
0 0 0 0 0 0 0 0
14h Vol. Control
B3 B3_VOL7 B3_VOL6 B3_VOL5 B3_VOL4 B3_VOL3 B3_VOL2 B3_VOL1 B3_VOL0
page 53
default
0 0 0 0 0 0 0 0
15h Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved
page 53
default
0 0 0 0 0 0 0 0
16h Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved
page 53
default
0 0 0 0 0 0 0 0
17h Channel
Invert Reserved Reserved INV_B3 INV_A3 INV_B2 INV_A2 INV_B1 INV_A1
page 53
default
0 0 0 0 0 0 0 0
18h Mixing Ctrl
Pair 1 P1_A=B Reserved Reserved P1_ATAPI4 P1_ATAPI3 P1_ATAPI2 P1_ATAPI1 P1_ATAPI0
page 53
default
0 0 0 0 1 0 0 1
19h Mixing Ctrl
Pair 2 P2_A=B Reserved Reserved P2_ATAPI4 P2_ATAPI3 P2_ATAPI2 P2_ATAPI1 P2_ATAPI0
page 53
default
0 0 0 0 1 0 0 1
1Ah Mixing Ctrl
Pair 3 P3_A=B Reserved Reserved P3_ATAPI4 P3_ATAPI3 P3_ATAPI2 P3_ATAPI1 P3_ATAPI0
page 53
default
0 0 0 0 1 0 0 1
1Bh Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved
page 53
default
0 0 0 0 1 0 0 1
1Ch ADC Left
Ch. Gain Reserved Reserved LGAIN5 LGAIN4 LGAIN3 LGAIN2 LGAIN1 LGAIN0
page 55
default
0 0 0 0 0 0 0 0
1Dh ADC Right
Ch. Gain Reserved Reserved RGAIN5 RGAIN4 RGAIN3 RGAIN2 RGAIN1 RGAIN0
page 55
default
0 0 0 0 0 0 0 0
1Eh
Interrupt
Control
SP_SYNC Reserved DE-EMPH1 DE-EMPH0 INT1 INT0 Reserved Reserved
page 55
default
0 0 0 0 0 0 0 0
1Fh Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved
default 0 0 0 0 0 0 0 0
20h Interrupt
Status UNLOCK Reserved Reserved Reserved Reserved Reserved OverFlow Reserved
page 56
default
X X X X X X X X
21h Interrupt
Mask UNLOCKM Reserved Reserved Reserved Reserved Reserved OverFlowM Reserved
page 57
default
0 0 0 0 0 0 0 0
22h Interrupt
Mode MSB UNLOCK1 Reserved Reserved Reserved Reserved Reserved OF1 Reserved
page 57
default
0 0 0 0 0 0 0 0
Addr Function 7 6 5 4 3 2 1 0
