3.2 Absolute Maximum Ratings
Characteristics conditions:
All voltages are measured with respect to GND.
Notes: 5. Long-term operation at the maximum junction temperature will result in reduced product life. Derate internal power
dissipation at the rate of 50mW/ °C for variation over temperature.
WARNING:
Operation at or beyond these limits may result in permanent damage to the device.
Normal operation is not guaranteed at these extremes.
Pin Symbol Parameter Value Unit
8 V
DD
IC Supply Voltage 19 V
1,2,3,4,5 - Analog Input Maximum Voltage -0.5 to (V
DD
+0.5) V
1,2,3,4,5 - Analog Input Maximum Current 50 mA
7 V
GD
Gate Drive Output Voltage -0.3 to (V
DD
+0.3) V
7 I
GD
Gate Drive Output Current -1.0 / +0.5 A
- P
D
Total Power Dissipation @ T
A
= 50 °C 600 mW
-

JA
Junction-to-Ambient Thermal Impedance 107 °C/W
- T
A
Operating Ambient Temperature Range -40 to +125 °C
- T
J Junction Temperature Operating Range 5 -40 to +125 °C
- T
Stg
Storage Temperature Range -65 to +150 °C
All Pins ESD
Electrostatic Discharge Capability Human Body Model
Charged Device Model
2000
500
V
V
