26 WIKA operating instructions, model CPC2000
11155094.02 07/2012 GB/D/F/E
GB
7. Interface
■ DATA-BITS: Defined value (8)
■ STOP-BITS: Defined value (1)
■ PARITY-BITS: Defined value (N)
7.4 Commands for serial interface
All interface commands are preceded by a colon and completed with the carriage return
(CR). Command and parameters must be separated by a space. By adding a question
mark to the appropriate action the parameter can be read rather than changed. Received
commands are acknowledged with SELECT, null or false commands with ERROR.
Command Answer function
Auto mode
:saaz <0 | 1>
Auto zero before each cycle (phase 4)
0 --> off
1 --> on
:acy <1 ... 100> Cycles to be carried out
1 ... 100 --> number of cycles
:asd <1 ... 100> Steps Down
1 ... 100 --> number of steps to reach the end point
:asu <1 ... 100> Steps Up
1 ... 100 --> number of steps to reach the end point
:ate <0 ... 10000> Delay time at the end point (phase 13)
1 ... 10000 --> time in seconds
:ath <1 ... 10000> Hold time (phase 10 and 16)
1 ... 10000 --> time in seconds
:atp <1 ... 10000> Pause time (phase 18)
1 ... 10000 --> time in seconds
:atr <1 ... 10000> Tolerance band
1 ... 10000 --> tolerance in 0.01 % FS (full scale) of the instrument
measuring range. Once the instrument has been controlled within
this tolerance band for 1 second, the hold time expires.
:ats <1 ... 10000> Start delay (phase 2)
1 ... 10000 --> time in seconds
Interface output
:o <0 | 1>
Output status information over interface
0 --> off
1 --> on
