6. Commissioning, operation

6.5.1.2 Unit

Here the unit, in which the low-pressure controller will display the measured value on the

screen, can be selected. Dependent upon the measuring range of the instrument, various

units are not available since they could not be displayed.

6.5.1.3 Steps

Here the step size for the STEP function, in x % of the set range, can be changed. Possi-

ble settings are from 1 … 50 %.

6.5.1.4 Mode

Here the operating mode of the controller can be set. The following modes can be

selected:

■

Measure (MEAS): The controller measures the pressure in the set pressure unit

■

Control (CTRL): A set point is automatically regulated.

■

Automatic (AUTO): A stored test routine will be carried out.

6.5.1.5 Language

Here the language in which the menu will be displayed can be set. There is the possibility

to choose between German, English, Spanish and French.

6.5.1.6 Settings

■

ZERO: Switching on and off of the automatic zero point adjustment following exit from

the menu. It is even possible to set at what intervals the instrument will automatically

perform a zero point adjustment.

■

RS232/USB: Selection of the appropriate serial interface

■

DISPLAY: Brightness setting

■

AUTO-MODE: Setting of the pressure range, the pressure unit and number of steps

the pressure range will be divided up into. The STEPS UP/STEPS DOWN can be

assigned different values.

■

INFO: Basic information on the instrument
