WIKA operating instructions model TGT73
2. Safety / 3. Specifications
Before mounting and commissioning the instrument,
ensure you read the operating instructions!
CE, Communauté Européenne
Instruments bearing this mark comply with the relevant
European directives.
3. Specifications
Gas-actuated thermometer model TGT73
Measuring element
Inert gas expansion system
Nominal size
100, 160
Instrument version
Back mount (axial)
Lower mount (radial)
Back mount, adjustable stem and dial
Instruments with capillaries
Permissible ambient temperature 0 ... 40 °C
Working range
■
Continuous load (1 year)
■
short term (max. 24 h)
Measuring range (EN 13190)
Scale range (EN 13190)
Case, ring
Stainless steel
Stem, process connection
Stainless steel 1.4571
Ingress protection
IP 65 per IEC 60529
2.4 Product label
Date of manufacture
Model
