G
D1
L1
L2
L3
L4
G ½ B
18
23
20.5
10
15.5
G
D1
L1
L2
L3
L4
G 1 B
30
23
20.5
10
15.5
G
D1
L1 L2 L3 L4
G 1 B hygienic
29.5
28
25
9
15.5
18
WIKA operating instructions pressure transmitter, model S-11
GB
14043046.01 06/2012 GB/D/F/E
For information on tapped holes and welding
sockets, see Technical information IN 00.14 at
www.wika.com.
6. Commissioning, operation
Dimensions of the process connections in mm
