RB-6 - Overview
3
Overview
The Kramer RB-6 is a high-performance, high-voltage power supply that supplies
power to up to six external units.
The RB-6 features:
Two power outlets with on/off push-button as well as full voltage control
Four power outlets with on/off push-button control
Individual push-button LEDs to indicate which outlets are live
Remote control via Ethernet (with built-in Web pages), RS-232 and RS-485
Availability in European and American versions
The RB-6 is housed in a 19-inch, 1U, rack-mountable enclosure and is powered
by a 100
–240V AC universal switching power supply. The RB-6 is for use in
Europe with 220V AC European power sockets and the RB-6 (US) is for use in
America with 110V AC American power sockets. RB-6 is printed on the front panel
of both models.
3.1
Using the IR Transmitter
You can use the RC-IR3 IR transmitter to control the machine via the built-in IR
receiver on the front panel or instead, via an optional external IR receiver (Model:
C-A35M/IRR-50). The external IR receiver can be located up to 15m (49ft) away
from the machine. This distance can be extended to up to 60m (197ft) when used
with three extension cables (Model: C-A35M/A35F-50).
Before using the external IR receiver be sure to arrange for your Kramer dealer to
insert the internal IR connection cable (P/N: 505-70434010-S) with the 3.5mm
connector that fits into the REMOTE IR opening on the rear panel. Connect the
external IR
receiver to the REMOTE IR 3.5mm connector.
