RB-6 - RB-6 Communication Protocol 31
31
12.1.7 Command Chaining
Multiple commands can be chained in the same string. Each command is
delimited by a pipe character ( '|' ). When chaining commands, enter the message
starting character and the message closing character only once, at the
beginning of the string and at the end.
Commands in the string do not execute until the closing character is entered.
A separate response is sent for every command in the chain.
12.1.8 Maximum String Length
64 characters
12.1.9 Backward Support
Protocol 2000 is transparently supported by Protocol 3000. You can switch
between protocols using a switch protocol command from either platform.
12.2 Supported Commands
For details regarding the commands, see the Kramer Protocol 3000 document.
The latest version of the document is available from http://www.kramerelectronics.com .
The following commands are supported by the RB-6.
Command Description Permission
# Protocol handshaking End User
BUILD-DATE? Read device build date End User
DIM_RANGE Set the dimmer range
DIM_RANGE? Read the dimmer range
DIM-VALUE Set the dimmer value
DIM-VALUE? Read the dimmer value
ETH-PORT Change protocol Ethernet port Administrator
ETH-PORT? Get protocol Ethernet port End User
FACTORY Reset to factory default configuration
HELP List of commands End User
LDFW Load new firmware User SW Internal
MODEL? Read device model End User
NAME Set machine (DNS) name Administrator
NAME? Get machine (DNS) name End User
NAME-RST Reset machine name to factory default (DNS) Administrator
NET-DHCP Set DHCP mode Administrator
