RB-6 - Operating the RB-6 Remotely Using the Web Pages 19
19
8 Operating the RB-6 Remotely Using the Web
Pages
8.1 Accessing the RB-6 Embedded Web Pages
The embedded Web pages can be used to remotely operate the RB-6 via a LAN
using the Ethernet connection (see Section
6.2
).
Before you can use the embedded Web pages, check that the Java™ software is
installed on your computer and that your computer is correctly connected to the
RB-6 via the Ethernet connection (see Section 6.2 ).
The Java software is available from
http://www.java.com .
A description of each Web page appears if you hover with your mouse over the
question mark that appears on the left side of the screen.
To run the RB-6 embedded Web pages:
1. Open your Internet browser.
2. Type the IP address (see Section 11 ) of the RB-6 in the address bar of your
browser (or the name, if using DHCP).
Figure 11: Entering the IP Address in your Browser
The screen shown in Figure 12 appears.
