7 Operating the RB-6 Locally
It is good working practice to turn off unused outputs.
7.1 Operating the RB-6 via the Front Panel Buttons
To operate outputs 1 to 4:
1. Press the required button to turn the output on.
The output is turned on and the relevant button LED lights.
2. Press the required button again to turn the output off.
The output is turned off and the button LED no longer lights.
To vary the voltage on outputs 5 and 6:

Turn the relevant output control knob clockwise to increase or anticlockwise
to decrease the output voltage.
The button LED flashes for a few seconds when the maximum or minimum
limit is reached, then lights solid
To set the output voltage to the minimum or maximum voltage on outputs 5
and 6:

Briefly press the relevant Min or Max button to set the output voltage to the
minimum or maximum output respectively.
The button LED flashes
To configure the lower and upper ranges for outputs 5 and 6:

With the output voltage already set to the required minimum or maximum
(percentage), press and hold either the Min or Max button for a few seconds
to configure that voltage as the minimum or maximum respectively.
The button LED lights solid
