Page 14: Section
10
RB-6 - Connecting the RB-6
3. Optional
—connect a PC via Ethernet over a LAN to the RB-6 for remote
control.
6.2
Connecting to the RB-6 via Ethernet
You can connect the RB-6 via Ethernet using a crossover cable (see
) for direct connection to the PC, or a straight through cable (see
) for connection via a network hub or network router.
After connecting the Ethernet port, you have to install and configure your Ethernet Port. For
detailed instructions, see the Ethernet Configuration Guide (Lantronix) in the technical support
section on our Web site
http://www.kramerelectronics.com
6.2.1
Connecting the Ethernet Port directly to a PC
You can connect the Ethernet port on the RB-6 to the Ethernet port on your PC
via a crossover cable with RJ-45 connectors.
This type of connection is recommended for identification of the
factory default IP Address of the RB-6 during the initial configuration
To configure your PC after connecting the Ethernet port:
1. Right-click the My Network Places icon on your desktop.
2. Select Properties.
3. Right-click Local Area Connection Properties.
4. Select Properties.
The Local Area Connection Properties window appears.
5. Select the Internet Protocol (TCP/IP) and click the Properties Button.
