VP-8x8 - Technical Specifications
21
21
7
Technical Specifications
INPUTS:
8 VGA on 15-pin HD connectors (VGA through UXGA)
OUTPUTS:
8 VGA on 15-pin HD connectors (VGA through UXGA)
MAX. OUTPUT LEVEL:
1.5Vpp
BANDWIDTH (-3dB):
400MHz
DIFF. GAIN:
0.04%
DIFF. PHASE:
0.04Deg.
K-FACTOR:
<0.05%
S/N RATIO:
75dB
CROSSTALK (all hostile):
–53dB
CONTROLS:
22 front panel buttons, RS-232, RS-485, Ethernet
COUPLING:
DC
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
POWER SOURCE:
100-264V AC, 50/60 Hz; 23VA
DIMENSIONS:
19” x 7” x 1U (W, D, H) rack-mountable
WEIGHT:
2.7kg (6lbs) approx.
ACCESSORIES:
Power cord, null modem adapter, Windows®-based
Kramer control software, infrared remote control
transmitter
OPTIONS:
External remote IR receiver cable
P/N: C-A35M/IRR-50
Specifications are subject to change without notice. For the most updated resolution list, go
to our Web site a
